ZINC BARREL ELECTROPLATING IN WISCONSIN
High-Volume Precision Corrosion Protection for Small Steel Components
In Wisconsin’s manufacturing environment—where winter road salts, humidity, agricultural exposure, and industrial conditions accelerate corrosion—zinc barrel electroplating provides a cost-effective, high-performance solution for protecting steel components.
For manufacturers producing large quantities of small parts, zinc barrel electroplating delivers the ideal balance of corrosion resistance, production efficiency, and affordability.
At Plateco, Inc., zinc plating is not a side service — it is our specialization. Our barrel electroplating systems are engineered for consistency, automation, and high-volume throughput while maintaining strict quality standards.
CONTACT US
What Is Zinc Barrel Electroplating?
Zinc barrel electroplating is an electrochemical process used to deposit a protective zinc coating onto small steel parts in bulk quantities.
Unlike rack plating—where parts are individually mounted—barrel plating loads hundreds or thousands of small components into a rotating barrel. The barrel tumbles inside a zinc electrolyte solution while electrical current flows through the system, allowing zinc ions to deposit onto the metal surfaces.
This process is specifically designed for:
- High-volume production
- Small to medium-sized components
- Fasteners and stampings
- Parts requiring cost efficiency
- Applications where cosmetic perfection is secondary to protection
How Zinc Barrel Electroplating Works
Zinc rack electroplating involves several controlled steps:
1. Bulk Part Loading
Large quantities of small steel components are placed into a perforated rotating barrel. The design allows plating solution to flow freely while maintaining electrical contact between parts.
2. Cleaning & Surface Preparation
Before plating begins, parts undergo a rigorous cleaning process:
- Degreasing to remove oils
- Acid pickling to remove oxides
- Rinsing for contamination control
Proper preparation is critical. Any contamination can compromise adhesion or cause plating defects.
3. Zinc Deposition
Once inside the electrolyte bath, electrical current passes through the solution and between the tumbling parts.
As current flows:
- Zinc ions are attracted to the negatively charged steel surfaces.
- A controlled zinc layer forms on every exposed surface.
- Continuous tumbling ensures even exposure to solution.
The tumbling action also helps solution penetrate blind holes and recesses, improving coverage consistency.
4. Post-Plating Treatments
After zinc deposition, parts typically receive a chromate conversion coating to enhance corrosion resistance and achieve specific finish colors such as:
- Clear (Blue)
- Yellow
- Black
- Olive Drab
- Custom finishes
These treatments significantly increase salt spray performance and extend service life.
Why Zinc Barrel Electroplating Is Ideal for Wisconsin Manufacturers
Wisconsin industries rely heavily on small steel components, including:
-
- Automotive fasteners
- Agricultural hardware
- Construction connectors
- Industrial brackets
- Machine screws
- Stampings and clips
Our equipment is optimized for:
-
Cost-effective high-volume processing
-
 Reliable corrosion resistance
-
 Scalable production capacity
-
 Efficient turnaround times
-
 Uniform coverage for small parts
In a climate with extreme temperature changes and road salt exposure, protecting these components is essential for product reliability.
Barrel Electroplating Capacity in Wisconsin
Located in Reedsburg, Plateco, Inc. operates fully automated zinc barrel electroplating lines designed for precision and throughput.
Our capabilities include:
- Processing up to 800 pounds per barrel
- Plating extremely small parts (down to very fine diameters)
- Controlled barrel rotation speeds for delicate components
- Automated chemistry monitoring for consistent deposition
Automation minimizes human error and increases repeatability — essential for high-volume OEM production.
Technical Advantages of Barrel Electroplating
Uniform Coverage on Complex Shapes
The tumbling motion ensures that parts shift continuously, allowing plating solution access to:
- Threads
- Blind holes
- Recessed features
- Undercuts
Cost Efficiency
Because many parts are plated simultaneously:
- Labor costs per part decrease
- Production time is reduced
- Energy usage is optimized
- Overall finishing costs remain competitive
Process Control & Quality Monitoring
High-quality barrel plating depends on strict operational control, including:
- Electrolyte chemistry balancing
- Current density regulation
- Thickness measurement
- Temperature control
- Contamination prevention
Corrosion Resistance Performance
Zinc barrel electroplating provides sacrificial protection. Even if the coating is scratched, zinc corrodes before the underlying steel.
Performance levels can be engineered by adjusting:
- Zinc thickness
- Chromate system
- Post-treatment sealers
This allows parts to meet specific corrosion resistance targets depending on their application environment.
When to Choose Barrel Electroplating Over Rack Plating
Barrel plating is best suited for:
✔ Small parts
✔ High-volume production
✔ Cost-sensitive applications
✔ Components not requiring cosmetic perfection
✔ Standard corrosion resistance requirements
Rack plating may be preferred for larger or highly cosmetic parts, but for most fasteners and small components, barrel plating delivers superior efficiency.
Industries in Wisconsin That Rely on Barrel Electroplating
Automotive Suppliers
Fasteners, clips, brackets, and mounting hardware exposed to road salt.
Agricultural Equipment
Outdoor hardware subjected to moisture and soil conditions.
Industrial Machinery Producers
Machine screws and internal mechanical components.
Construction Hardware Companies
Anchors, bolts, and connectors exposed to weather.
The Advantage of Working with a Zinc Specialist
Unlike general metal finishing companies, Plateco, Inc. focuses exclusively on zinc plating.
This specialization provides:
- Deeper technical knowledge
- Refined operational systems
- Continuous process optimization
- Consistent coating performance
- Reduced defect rates
Our philosophy is simple:
On Spec. On Time. Or It’s On Us.
Environmental & Compliance Standards
Modern zinc barrel electroplating systems are designed to meet environmental and regulatory standards while maintaining efficiency.
We are capable of plating to widely recognized industry specifications such as:
- ASTM B633
- Customer-specific OEM standards
- Industry corrosion performance requirements
Documentation and traceability are available to support quality audits and compliance reviews.
Frequently Asked Questions
Q: Is zinc barrel electroplating suitable for threaded parts?
Yes. The tumbling motion allows solution access to threaded features, providing consistent coverage.
Q: Can very small parts be plated?
Yes. Specialized barrel configurations allow plating of extremely small components.
Q: Is barrel plating as durable as rack plating?
For small components and high-volume production, barrel plating provides comparable corrosion protection when properly controlled.
Q: Does barrel plating damage parts?
With controlled rotation speeds and proper loading practices, part damage is minimized and managed carefully.
Partner with Wisconsin’s Zinc Barrel Electroplating Experts
If your operation requires high-volume corrosion protection for small steel components, zinc barrel electroplating provides the performance and efficiency needed to stay competitive.
At Plateco, Inc., our automated barrel lines, disciplined quality systems, and zinc-only specialization ensure reliable results for manufacturers across Wisconsin.
Request a Quote
Share your part specifications, annual volume, and corrosion requirements. Our team will recommend the most efficient zinc barrel electroplating solution for your application.
